© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 256
3 Check the generator belt tension, if not within specification continue with the following adjustment steps.
See Drive Belt Gauge Instructions.
Generator Belt Tension Specification
85 +/- 5 lbs (38.6 +/- 2.3 kgs)
60 - 75 lbs (27.2 - 34 kgs)
Note: * More than 1 hour of use.
4 Loosen or tighten the generator adjustment nut and bolt until the belt gauge reads approximately 90 lbs.
5 Tighten the generator mounting bolts.
6 Select the QUICKSTART program and adjust the resistance up ▲ key until resistance level 10 is
displayed. Pedal the AMT for approximately one minute and then recheck the belt tension.
7 Recheck the drive input belt and the generator belt tension, readjust if out-
of-spec. See Drive Belt Gauge Instructions.
FIGURE 253: GENERATOR
