© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 252
3 Set the ohmmeter to a range that will conveniently read up to 50 Ω (Ohms).
4 Remove the two wires from the LOAD terminals of the lower PCA.
5 With an ohmmeter, read between the wires removed in step 4. The reading should be approximately 10
Ω (Ohms). Replace the two wires removed in step 4.
6 Remove the three wires from the 3 PHASE GEN IN terminals of the lower PCA.
7 With an ohmmeter, read between the red & white, red & black and white & black wires. Each reading
should be approximately 25 Ω (Ohms). Reconnect the wires removed in step 6.
8 If the readings are still incorrect, replace the three phase generator.
9 Reconnect the red battery wire removed in step 3.
10 Replace the right side cover as per, Cover Replacement (on page 53).
Inspecting and Adjusting the H-brake Belt Tension
WARNING: Before continuing with this procedure, review the Warning and Caution statements listed
in the Warning and Caution Statements and General Safety Guidelines Section, Things You Should
Know.
Procedure
1 Remove the gasket, top, front, rear, left and right side covers per, Cover Replacement (on page 53)
Procedure .
2 Place a belt gauge on the H-brake belt.
FIGURE 250: H-BRAKE BELT TENSION GAUGE
