© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 257
Inspecting and Adjusting the Drive Input Belt Tension
WARNING: Before continuing with this procedure, review the Warning and Caution statements listed
in the Warning and Caution Statements and General Safety Guidelines Section, Things You Should
Know.
Procedure
1 Remove the gasket, top, front, rear, left and right side covers per, Cover Replacement (on page 53)
Procedure .
2 Place a belt gauge to the drive input belt as shown below.
FIGURE 254: DIVE INPUT BELT
To Next Page
