3 Check the drive input belt tension, if not within specification continue with
the following adjustment steps. See Drive Belt Gauge Instructions
Drive Belt Tension Specification
135 +/- 5 lbs (61.2 +/- 2.3 kgs)
100 - 125 lbs (45.4 - 56.7 kgs)
Note: * More than 1 hour of use.
4 Loosen the generator mounting bolts.
5 Loosen the generator adjustment bolt.
FIGURE 255: GENERATOR
