Rear Flat Belt Terminal Cover Replacement
1 Remove the two screws that secure the flat belt covers to the flat belt terminal, remove the outside
terminal cover.
2 Rotate the inside terminal cover down until it is below the stairarm pedal, pull to remove.
3 Align the top of the replacement inside cover so that it is pointing toward the floor. Place the bottom of
the cover in between the flat belt terminal and the stairarm pedal. Rotate the top of the cover up and in
to place.
4 Fasten the outside and inside terminal cover to the flat belt terminal using the two #10-24 X 1.25 screws.
FIGURE 18: FLAT BELT TERMINAL COVERS
