Precor AMT12 base - Page 196

© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law Page 196
25 The belt gauge should read approximately 120 ± 10 lbs. If the belt tension is significantly high or low the
belt tension may be adjusted by following the steps below. See Drive Belt Gauge Instructions (on
page 265)
26 Loosen or tighten the step up pulley adjustment bolt until the belt gauge reads approximately 160 lbs.
See Drive Belt Gauge Instructions (on page 265)
