86506-00 Date: May 18, 2001
SERVICE PARTS LIST
Customer Name: Prevost Car ISRI Model: 6801/525
ISRI P/N: 86506-00 Customer P/N: 860912
Seat Specification: LH controls, 16 degree restriction, Air lumbar/Manual valve
(IPS5), Adjustable shock, Armrest-padded, Long air supply
hose
Property / User / Application: Prevost Car motor coach
ILLUS
NO.
DESCRIPTION ISRI P/N CUSTOMER P/N
A Headrest Kit ------------
B Armrest Kit ------------
C-024 Backrest Asm 17518-00 860739
D-008 Seat Pan Asm 14663-04 860742
E-059 Seat Frame Asm 02371-02 861099
F-016 Static Spacer 18191P 861083
G Swivel Asm ------------
H Isolator Asm ------------
J-006 Slide Set 17491 860758
K-019 Suspension Asm 17259-01
L-004 ICP Bar 23914P
M-001 Boot Kit 92625-01 860523
N Riser ------------
P Seat Belt Kit ------------
Assembly Hardware
Bolt-Hex Hd (Backrest) 60199
Screw (Seat Pan) 60560
Nut-Hex-Nylon Lock-M8 60016
Bolt-Soc Hd-M8 x 16 60185
Bolt-Soc Hd-M8 x 20 60172
Spacer 40432B
Washer-Lock-A8.2 60400
Bolt-Hex Hd-M8 x 25 60055
Nut-Hex-Crimp Lock-M8 60008
L-004 Cover Plate – ICP Bar 34824D
To Next Page
