17491 Date: May 23, 2001
SERVICE PARTS LIST
ISRI P/N: 17491 Description: Slide Set – “B” Style
ISRI Illus. No.: J-006
Customer: Prevost Car Customer P/N: 860758
Specification: 90/60 slide stroke, double locking, bar handle up
ILLUS
NO.
DESCRIPTION ISRI P/N CUSTOMER P/N
J1 Handle – Slide See J8
J2 Slide – Slave – LH 23908
J3 Slide – Master – RH 23907
J4 Spring – Handle Return – LH 43284C
J5 Spring – Handle Return – RH 43283C
J6 Ring – Retaining See J8
J8 Handle/Clip Kit 914212-04
To Next Page
