Page 1 of 2 17259-01 Date: May 23, 2001
SERVICE PARTS LIST
ISRI P/N: 17259-01 Description: Susp–Air
ISRI Illus. No.: K-019
Customer: Prevost Car Customer P/N:
Specification: Manual air, 100 mm stroke, Adjustable shock
ILLUS
NO.
DESCRIPTION ISRI P/N CUSTOMER P/N
K2 Suspension Hdw Kit 95477-03 860770
K3 Bumper / Bracket Asm See K12
K5 Shock Kit 914410 860766
K6 Air Spring Kit 95474-02
K12 Bumper Kit 913934-05 860769
K19 Shock Cable Kit 914411 860767
K20 Shock Handle Kit 914412-01 861105
K50 Nut – Hex – M8 See K12
K51 Washer – Split Lock – B8 See K12
K53 Bumper – Cone Shape See K12
K56 Bushing – Flange See K2
K59 Nut–Hex–Crimp Lock-M10 See K2
K61 Spring – Air See K6
K66 Washer – Flat – A6.4 See K6
K67 Screw – Air Spring Mtg - Lwr See K6
K69 Bracket – Bumper Stop See K3
K70 Bumper – Up Stop See K3
K72 Bolt – Shock Mtg - Lower See K5
K73 Hose–MV / Air Spring See K16
K75 Bolt – Shoulder – M10 See K2
K78 Roller See K2
K83 Bushing – Shock - Lower See K5
K84 Shock Absorber See K5
K106 Frame – Upper N/A Separate
K108 Frame – Lower N/A Separate
K109 Scissor – Outer N/A Separate
K110 Scissor – Inner N/A Separate
K125 Cable Tie See K5 or K9
K152 Spacer Block See K2
K153 Bearing Block See K2
K154 Bolt – Air Spring Mtg – Upr See K6
*PART OF KIT
