PREVOST X3-45 Multiplex User Manual

PROCEDURE NO: PR060034 REVISION 4
Page 7 of 15
1.40
Kidde Automatic Fire Detection and
Suppression System (optional)
Disconnect C466
Kidde AFSS module is located on the
lateral control panel.
1.45 When all the previous steps are done, you
can do welding on the vehicle
ENSURE THAT THE WELDING GROUND RETURN
CLAMP IS WELL SECURED AND MAKES A GOOD
ELECTRICAL CONTACT WITH A LARGE METALLIC
AREA OF THE CHASSIS LOCATED NEAR THE WELDING
POINT AS MUCH AS POSSIBLE.
1.50
When welding is completed, reconnect
all the modules.
Make sure that the connectors locking tab
are well engaged
BE CAREFUL TO MAKE THE PROPER CONNECTIONS, IF
NOT, SOME SYSTEMS OR COMPONENTS MAY NOT BE
USABLE

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
