PREVOST X3-45 Multiplex User Manual

Section 07: TRANSMISSION
PA1562
22
2. Begin operating as normal. Have the
transmission checked at the earliest
opportunity by an Allison Transmission
distributor or dealer.
NOTE
All active indicators are cleared at TCM power
down.
Some codes will clear their active indicator
when the condition causing the code is no
longer detected by the TCM.
The Diagnostic Display Mode can be exited by
any of the following methods:
o Press simultaneously the
(Up) and
(Down) arrow buttons at the same time on
the pushbutton shift selector.
o Press any range button «D», «N» or «R» on
the pushbutton shift selector (the shift will be
commanded if it is not inhibited by an active
code).
o Wait until the calibrated time (approximately
10 minutes) has passed. The system will
automatically return to the normal operating
mode.
o Turn off power to the TCM (shut off the
engine using the ignition key).
NOTE
If clearing a code while locked in a «D» (Drive)
or «R» (Reverse) position (fail-to-range), the
transmission will still be in «D» (Drive) or «R»
(Reverse) when the clearing procedure is
completed. «N» (Neutral) must be manually
selected.
9.5 DIAGNOSTIC CODE RESPONSE
The following responses are used in the
"Diagnostic Troubleshooting Code List and
Inhibited Operation Description" table to
command safe operation when diagnostic codes
are sent.
DNS - Do Not Shift
Response
Release lock up clutch and inhibit lock up
operation.
Inhibit all shifts.
Turn ON the CHECK TRANS light.
Display the range attained.
Ignore any range selection inputs from the shift
selector.
DNA - Do Not Adapt
Response
The TCM stops adaptive shift control while the
code is active.
SOL OFF - SOLenoid OFF
Response
All solenoids are commanded OFF (turning
solenoids “A” and “B” off electrically cause them
to be on hydraulically).
RPR - Return to Previous Range Response
When the speed sensor ratio or C3 pressure
switch test associated with a shift not
successful, the TCM commands the same range
as commanded before the shift.
NNC - Neutral No Clutches Response
When certain speed sensor ratio or C3 pressure
switch tests are not successful, the TCM
commands a neutral condition with no clutches
applied.
