SECTION 01: ENGINE
PA1562
27
SPN FMI PID/SID
PID/SID
ID
FLASH
CODES
FAULT DESCRIPTION
602 19 SID 242 2144 J1939 Cruise Control Accelerate Switch Signal
from Source #2 is erratic
602 13 SID 242 2144 J1939 Cruise Control Accelerate Switch Signal
from Source #2 is missing
602 19 SID 242 2144 J1939 Cruise Control Accelerate Switch Signal
from Source #3 is erratic
602 13 SID 242 2144 J1939 Cruise Control Accelerate Switch Signal
from Source #3 is missing
608 14 SID 250 2145 J1708 Data Link Failure
609 12 SID 233 2145 CPC2 Hardware Failure
615 9 SID 231 2615 J1939 DM1 Message from Transmission is missing
625 13 SID 248 2151 ECAN ID_1629 Diagnostic Message Not Received
This Ignition Cycle
625 9 SID 248 2151 ECAN ID_1629 Diagnostic Message No Longer
Being Received
625 10 SID 248 2151 ECAN ID_1629 Reporting Inconsistent Number of
Frames
625 2 SID 248 2151 ECAN ID_1629 Diagnostic Message Reporting
Data Not Available
625 14 SID 248 2151 ECAN ID_1629 Diagnostic Message Reporting an
Unknown MUID
625 9 SID 248 2151 Incorrect MCM System ID Received
625 9 SID 248 2151 MCM System ID Not Received or Stopped Arriving
625 4 SID 248 2151 ECAN Link Circuit Failure
628 14 SID 254 2151 XFLASH Static Fault Code Memory Page Read
Write Failure
628 13 SID 155 2615 20ms ECU OS Task Locked in an Endless Loop
628 13 SID 155 2615 20ms ECU OS Task Timed out Prior to Completion
628 13 SID 155 2615 1000ms ECU OS Task Locked in an Endless Loop
628 13 SID 155 2615 1000ms ECU OS Task Timed out Prior to
Completion
629 2 SID 254 2151 CPC Hardware/Software Mismatch
629 12 SID 254 2151 DDEC Data Xflash Write Error. Replace CPC2.
630 2 SID 253 2152 EEPROM Checksum Failure
630 2 SID 253 2152 EEPROM Checksum Failure for the SCR Block
630 13 SID 253 2152 SCR Number Out of Range
630 14 SID 155 2615 MCM Fault Codes Unavailable via J1939 and
J1587
