PREVOST X3-45 Multiplex User Manual

SECTION 01: ENGINE
PA1562
29
SPN FMI PID/SID
PID/SID
ID
FLASH
CODES
FAULT DESCRIPTION
972 2 SID 203 2243 Throttle inhibit switch signal not plausible due to
excess vehicle speed
973 9 SID 231 2615 J1939 EBC1 Message is missing
973 13 SID 231 2244 J1939 Engine Retarder Selection Signal Missing
973 19 SID 231 2244 J1939 Engine Retarder Selection Signal Erratic
974 2 PID 372 2245 Remote Accelerator Pedal Supply Voltage Out of
Range
974 3 PID 372 2245 Remote Accelerator Pedal Circuit Failed High
974 4 PID 372 2245 Remote Accelerator Pedal Circuit Failed Low
981 0 SID 155 2311 PTO CC+ and CC- Switches Pressed
Simultaneously
986 9 SID 231 2615 J1939 CM1 Message is missing
1267 4 SID 123 2312 Digital Output 4 10 Circuit Failed Low
1267 3 SID 123 2312 Digital Output 4 10 Circuit Failed Open
1321 4 SID 128 2314 Starter Lockout Output Shorted to Ground
1321 3 SID 128 2314 Starter Lockout Output Open Circuit
1590 19 SID 155 2615 Adaptive Cruise Control Message Not Received
1590 9 SID 231 2615 Adaptive Cruise Control Device Reporting Error
1624 9 SID 231 2615 J1939 TCO1 Message is missing
1624 19 SID 231 2315 J1939 Tachograph Vehicle Speed Signal is erratic
1624 13 SID 231 2315 J1939 Tachograph Vehicle Speed Signal is missing
1663 7 SID 123 2321 Optimized Idle Safety Loop Faulted
1716 9 SID 231 2615 J1939 ERC1 Message is missing
1845 9 SID 231 2615 J1939 TCFG2 Message is missing
2623 14 PID 91 2322 Pwm Accelerator Pedal GAS1 and GAS2 Signal
Missing
2623 8 PID 91 2322 Pwm Accelerator Pedal Signal 2 Frequency Out Of
Range
2900 9 SID 231 2615 J1939 ETC7 Message is missing
3510 3 SID 211 2333 Accelerator Pedal Supply Voltage Circuit Failed
High
3510 4 SID 211 2333 Accelerator Pedal Supply Voltage Circuit Failed
Low
3510 4 SID 211 2333 Pwm Accelerator Pedal Supply Voltage Missing
3510 3 SID 211 2333 Accelerator Pedal Supply Voltage Circuit Failed
High
3606 9 SID 231 2615 J1939 ESS Message is missing
3695 2 SID 155 2334 Manual DPF Regen and DPF Inhibit Switch
Rationality Fault
