5 Appendix I — System Configuration Layouts
41
Meritor WABCO Maintenance Manual MM-0112 (Revised 07-05)
5 Append ix I — System Configurat ion Layouts
ABS Configurations
Refer to Figure 5.1, Figure 5.2, Figure 5.3, Figure 5.4, Figure 5.5, Figure 5.6 and Figure 5.7 for system configuration layouts.
Figure 5.1
Figure 5.2
Figure 5.3
Figure 5.4
Figure 5.1
Figure 5.2
1003363e
LAMPS
AIR LINES
ELEC. LINES
LAMPS (UP TO THREE: ABS, TRAILER ABS, ATC)
VALVE PACKAGE
INSTALLATION (REAR)
STANDARD OR BASIC 4S/4M ABS
VALVE PACKAGE
INSTALLATION (FRONT)
1003364e
LAMPS
VALVE PACKAGE
INSTALLATION (REAR)
6S/4M ABS
AIR LINES
ELEC. LINES
LAMPS (UP TO THREE: ABS, TRAILER ABS, ATC)
VALVE PACKAGE
INSTALLATION (FRONT)
Figure 5.3
Figure 5.4
1003365e
LAMPS
AIR LINES
ELEC. LINES
VALVE PACKAGE
INSTALLATION (REAR)
6S/6M ABS
LAMPS (UP TO THREE: ABS, TRAILER ABS, ATC)
VALVE PACKAGE
INSTALLATION (FRONT)
1003366e
AIR LINES
ELEC. LINES
VALVE PACKAGE
INSTALLATION (REAR)
4S/4M ABS/ATC
LAMPS (UP TO THREE: ABS, TRAILER ABS, ATC)
LAMPS
ATC VALVE
VALVE PACKAGE
INSTALLATION (FRONT)
