PREVOST X3-45 Multiplex User Manual

SECTION 01: ENGINE
PA1562
41
SPN FMI PID/SID
PID/SID
ID
FLASH
CODE FAULT DESCRIPTION
4076 2 SID 155 1615 Engine Coolant Sensor (IN), General Temp. Plausibility Error
4077 4 SID 332 1543 Doser Fuel Line Pressure Sensor Circuit Failed Low
4077 3 SID 332 1543 Doser Fuel Line Pressure Sensor Circuit Failed High
4077 14 SID 332 1543 Doser Fuel Line Pressure Failed Self Test
4226 4 SID 155 1615 Compressor Differential Pressure Inlet Failed Low
4226 3 SID 155 1615 Compressor Differential Pressure Inlet Failed High
4226 0 SID 155 1615 Turbocharger Compressor Inlet Differential Pressure Too High (Low Box)
4226 1 SID 155 1615 Turbocharger Compressor Inlet Differential Pressure Too Low (High Box)
4226 5 SID 155 1615
Turbocharger Compressor Inlet Differential Pressure Sampling Range
Failure
4226 13 SID 155
1454 Turbocharger Compressor Inlet Differential Pressure Sensor Out Of
Calibration
4226 13 SID 155
1454 Turbocharger Compressor Inlet Differential Pressure Sensor Out Of
Calibration
4227 4 SID 53 1324 Electrostatic Oil Separator Circuit Failed Low
4227 3 SID 53 1324 Electrostatic Oil Separator Circuit Failed High
4227 5 SID 53 1324 Electrostatic Oil Separator Circuit Failed Open
4227 4 SID 155 1615 Oil Separator Circuit Failed Low
4227 3 SID 155 1615 Oil Separator Circuit Failed High
4227 7 SID 155 1615 Oil Separator, Max. Duration Time Reached
4228 16 SID 147
1241 Smart Remote Actuator 5 (VGT), Temperature Fault
4228 15 SID 147
1241 Smart Remote Actuator 5 (VGT), Temperature Warning
