PREVOST X3-45 Multiplex User Manual

13
3
Rim area
3-10
Check the entire rim area for nicks, gouges and cracks. Loss of air may be caused by cracks in
areas around the valve stem hole. Remove the wheel from service.
Bead Seat area
3-11
Loss of air may be caused by cracks in the bead seat areas around the rim. Remove the
wheel from service if damaged.

Bead seat cracks are normally caused by overloading of the wheels. If you have this type of
wheel breakage it would be recommended to use SEVERE SERVICE WHEELS.


Valve hole crack
Drop center crack

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
