6. Prepare for fluid drainage and remove 4 bolts (4),
and washers (5).
Remove bolts
5. Make a mark across the housing (1) and cover (21)
to make reassembly easier.
Mark cover
orientation
7. Separate the housing (1) from the cover (21) using a
twisting motion.
Remove housing
8. Remove the spring (10).Remove spring
Marker, solvent
proof
9/16" Socket
Wear eye protection. The spring
(10) will make the housing jump,
and may fly out. Make sure you hold the housing tightly
when removing.
9. Make a line across remaining internal components
to make reassembly easier.
Mark internal
components
Marker, solvent
proof
CAUTION
!

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
