Bosch Rexroth AGTS 2plus 4.2 3–59
b
1)
l
2)
KT v
N
3)
U, f RV GP AT MA Nr./No./N°
[mm] [mm] [m/min]  11-122
160 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K/S S; K R; L 3 842 999 904
240 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M b = … mm
320 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M l = … mm
400 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M KT = …
480 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M v
N
= … m/min
640 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M U = …
800 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M f = … Hz
1040 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; M RV = …
160-1040 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 0; 1 K; S S; K R; L; (M) GP = …
AT = …
MA = …
b
l
00013198.eps
b
1)
l
2)
KT v
N
3)
U, f GP AT MA Nr./No./N°
[mm] [mm] [m/min]  11-122
160 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L 3 842 998 096
240 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18
K; S S; K R; L b = … mm
320 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L l = … mm
400 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L KT = …
480 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L v
N
= … m/min
640 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L U = …
800 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L f = … Hz
1040 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L GP = …
160-1040 300-6000 1, 2, 3, 4 0; 6; 9; 12; 15; 18 K; S S; K R; L AT = …
MA = …
M
MA = L
R
00116761.eps
300 kg
700 kg
Längstransport · Longitudinal conveyor · Transport longitudinal
3 842 531
138 (2013-06)
Bandstrecke BS 2/R-300
BS 2/R-300 belt section
Section à bande BS 2/R-300
Bandstrecke BS 2/R-700
BS 2/R-700 belt section
Section à bande BS 2/R-700
1)
b = Spurbreite in Transportrichtung
2)
l = Länge
3)
v
N
= Nenngeschwindigkeit;
v
N
= 0: ohne Motor und ohne Getriebe
Sonderausführungen auf Anfrage
1)
b = Track width in direction of transport
2)
l = Length
3)
v
N
= Nominal transportation speed;
v
N
= 0: without motor or gear
Special models on request
1)
b = Ecart. de voie en direction du transport
2)
l = Longueur
3)
v
N
= Vitesse nominale de transport ;
v
N
= 0 : sans moteur et sans engrenage
Versions spéciales sur demande
MA = Motoranordnung
MA = Motor layout
MA = Disposition du moteur
