Bosch Rexroth AGTS 2plus 4.2 3–65
b
1)
v
N
2)
U, f MA RV AT Nr./No./N°
[mm] [m/min]   11-122
160 0; 6; 9; 12; 15; 18 R; L 0; 1 S; K 3 842 998 052
240 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K b = … mm
320 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K v
N
= … m/min
400 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K U = … V
480 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K f = … Hz
640 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K MA = …
800 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K RV = ...
1040 0; 6; 9; 12; 15; 18 R; L; M 0; 1 S; K AT = …
160-1040 0; 6; 9; 12; 15; 18
R; L; (M) 0; 1 S; K
b
1)
v
N
2)
U, f AT MA Nr./No./N°
[mm] [m/min]   11-122
160 0; 6; 9; 12; 15; 18 S; K R; L 3 842 998 072
240 0; 6; 9; 12; 15; 18 S; K R; L b = … mm
320 0; 6; 9; 12; 15; 18 S; K R; L v
N
= … m/min
400 0; 6; 9; 12; 15; 18 S; K R; L U = … V
480 0; 6; 9; 12; 15; 18 S; K R; L f = … Hz
640 0; 6; 9; 12; 15; 18 S; K R; L AT = …
800 0; 6; 9; 12; 15; 18 S; K R; L MA = …
1040 0; 6; 9; 12; 15; 18 S; K R; L
160-1040 0; 6; 9; 12; 15; 18 S; K R; L
b
AS 2/R-700
AS 2/R-300
00012912.eps
M
MA = L
R
00116761.eps
300 kg
700 kg
Längstransport · Longitudinal conveyor · Transport longitudinal
3 842 531
138 (2013-06)
Antriebsstation AS 2/R-300
AS 2/R-300 drive module
Poste d’entraînement AS 2/R-300
Antriebsstation AS 2/R-700
AS 2/R-700 drive module
Poste d’entraînement AS 2/R-700
1)
b = Spurbreite in Transportrichtung
2)
v
N
= Nenngeschwindigkeit;
v
N
= 0: ohne Motor und ohne Getriebe
Sonderausführungen auf Anfrage
1)
b = Track width in direction of transport
2)
v
N
= Nominal transportation speed;
v
N
= 0: without motor or gear
Special models on request
1)
b = Ecart. de voie en direction du transport
2)
v
N
= Vitesse nominale de transport ;
v
N
= 0 : sans moteur et sans engrenage
Versions spéciales sur demande
MA = Motoranordnung
MA = Motor layout
MA = Disposition du moteur
