Bosch Rexroth AGTS 2plus 4.2 5–7
b
Q
b
L
a v
N
U, f AT Nr./No./N°
[mm] [mm] [mm] [m/min]  11-122
160 160
1)
45 0; 6; 9; 12; 15; 18 S; K 3 842 999 894
160 240 45; 90 0; 6; 9; 12; 15; 18 S; K b
Q
= … mm
160 320 45; 90 0; 6; 9; 12; 15; 18 S; K b
L
= … mm
240 160
1)
45 0; 6; 9; 12; 15; 18 S; K a = … mm
240 240 45; 90 0; 6; 9; 12; 15; 18 S; K v
N
= … m/min
240 320 45; 90 0; 6; 9; 12; 15; 18 S; K U = … V
240 400 45; 90; 135 0; 6; 9; 12; 15; 18 S; K f = … Hz
320 160
1)
45 0; 6; 9; 12; 15; 18 S; K AT = ...
320 240 45; 90 0; 6; 9; 12; 15; 18 S; K
320 320 45; 90 0; 6; 9; 12; 15; 18 S; K
320 400 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
400 240 45; 90 0; 6; 9; 12; 15; 18 S; K
400 320 45; 90 0; 6; 9; 12; 15; 18 S; K
400 400 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
400 480 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
480 320 45; 90 0; 6; 9; 12; 15; 18 S; K
480 400 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
480 480 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
640 400 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
640 480 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
800 400 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
800 480 45; 90; 135 0; 6; 9; 12; 15; 18 S; K
00116798.eps
b
Q
b
L
a
5
6
978
4
3
2
1
EQ 2/TR
Quertransport · Transverse conveyor · Transport transversal
3 842 531
138 (2013-06)
Elektrischer Quertransport EQ 2/TR
EQ 2/TR electrical transverse conveyor
Convoyeur transversal électrique EQ 2/TR
1)
N’est pas adapté pour les sections
ST 2/B-100, ST 2/C-100 et ST 2/R-100.
1)
Not suitable for conveyor sections
ST 2/B-100, ST 2/C-100, and ST 2/R-100.
1)
Nicht geeignet für Strecken
ST 2/B-100, ST 2/C-100 und ST 2/R-100.
