Bosch Rexroth AGTS 2plus 4.2 5–17
00012789.eps
b
Q
b
L
HQ 2/S
Baugröße/Size/Taille b
Q
b
L
v
N
U, f Nr./No./N°
BG
[mm] [mm] [m/min]
11-122
BG 1 160 160
1)
, 240, 320 0; 6; 12; 15; 18 S; K
3 842 999 888
BG 1 240 160
1)
, 240, 320, 400 0; 6; 12; 15; 18 S; K
b
Q
= … mm
BG 1 320 160
1)
, 240, 320, 400 0; 6; 12; 15; 18 S; K
b
L
= … mm
BG 1 400 240, 320, 400 0; 6; 12; 15; 18 S; K
v
N
= … m/min
BG 1 480 320 0; 6; 12; 15; 18 S; K
U = … V
BG 2 400 480 0; 6; 12; 15; 18 S; K
f = … Hz
BG 2 480 400, 480 0; 6; 12; 15; 18 S; K
AT = …
BG 2 640 400, 480 0; 6; 12; 15; 18 S; K
BG 2 800 400, 480 0; 6; 12; 15; 18 S; K
Quertransport · Transverse conveyor · Transport transversal
3 842 531
138 (2013-06)
Hub-Quereinheit HQ 2/S
HQ 2/S lift transverse unit
Unité de levée transversale HQ 2/S
1)
Nicht geeignet für Strecken ST 2/B-100,
ST 2/C-100 und ST 2/R-100.
1)
N’est pas adapté pour les sections
ST 2/B-100, ST 2/C-100 et ST 2/R-100.
1)
Not suitable for conveyor sections
ST 2/B-100, ST 2/C-100, and ST 2/R-100.
