Bosch Rexroth AGTS 2plus 4.2 5–25
b l v
N
U, f AT MA ZA UB
1)
Nr./No./N°
[mm] [mm] [m/min]  11-122
160 240-6000 0; 6; 9; 12; 15; 18 S; K R; L N, A 1 3 842 999 723
240 240-6000 0; 6; 9; 12; 15; 18 S; K R; L N, A 1 b = … mm
320 240-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N, A 1 l = … mm
400 240-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N, A 1; 2 v
N
= … m/min
480 240-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N, A 1; 2 U = … V
640 240-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N, A 2 f = … Hz
800 240-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N, A 2 AT = …
MA = …
UB = …
ZA = …
00116780.eps
l
b
60 kg
BS 2/T-E
MA = R
Quertransport · Transverse conveyor · Transport transversal
3 842 531
138 (2013-06)
Bandstrecke BS 2/TE
BS 2/TE belt section
Section à bande BS 2/TE
1)
UB: Übertrieb für HQ 2-Baugröße
BG 1 oder BG 2.
1)
UB: connection belt for HQ 2 size
BG 1 or BG 2.
1)
UB : Courroie de liaison pour HQ 2 de taille
BG 1 ou BG 2.
