REXROTH TS 2plus - Page 207

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Bosch Rexroth AGTS 2plus 4.2 5–31
b
Q
b
L
v
N
U, f AT Nr./No./N°
[mm] [mm] [m/min]  11-122
160 160
1)
, 240, 320 0; 6; 9; 12; 15; 18 S; K 3 842 999 903
240 160
1)
, 240, 320, 400 0; 6; 9; 12; 15; 18 S; K b
Q
= … mm
320 160
1)
, 240, 320, 400 0; 6; 9; 12; 15; 18 S; K b
L
= … mm
400 240, 320, 400 0; 6; 9; 12; 15; 18 S; K v
N
= … m/min
480 320 0; 6; 9; 12; 15; 18 S; K U = … V
f = … Hz
AT= …
b
Q
b
L
00016587
HQ 2/U
Quertransport · Transverse conveyor · Transport transversal
3 842 531
138 (2013-06)
Hub-Quereinheit HQ 2/U
HQ 2/U lift transverse unit
Unité de levée transversale HQ 2/U
1)
Nicht geeignet für Strecken ST 2/B-100,
ST 2/C-100 und ST 2/R-100.
1)
N’est pas adapté pour les sections
ST 2/B-100, ST 2/C-100 et ST 2/R-100.
1)
Not suitable for conveyor sections
ST 2/B-100, ST 2/C-100, and ST 2/R-100.
