REXROTH TS 2plus - Page 222

Bosch Rexroth AG TS 2plus 4.26–6
b a h
SZ
Nr./No./N°
[mm] [mm] [mm]
160-400 45; 90; 135 250-2000 3 842 999 818
b = …mm
a = …mm
h
SZ
= …mm
00116813.eps
2(b+15)+a-90
2(b+15)+a
b
b
a
h
SZ
45
120
45
b a h
SZ
Nr./No./N°
[mm] [mm] [mm]
160-400 45; 90; 135 250-2000 3 842 998 237
b = …mm
a = …mm
h
SZ
= …mm
00125222.eps
h
SZ
45
45
2 (b + 25) + a - 90
2 (b + 25 )+ a
150
90
b
a
b
SZ 2/T
SZ 2/T-H
Stützen · Leg sets · Supports
3 842 531
138 (2013-06)
Streckenstützen SZ 2/T, SZ 2/T-H
SZ 2/T, SZ 2/T-H leg sets
Supports de section SZ 2/T, SZ 2/T-H
Streckenstützen SZ 2/…
SZ 2/… leg sets
Supports de section SZ 2/…
Streckenstütze SZ 2/T
SZ 2/T leg set
Support de section SZ 2/T
Streckenstütze SZ 2/T-H
SZ 2/T-H leg set
Support de section SZ 2/T-H
