Bosch Rexroth AGTS 2plus 4.2 3–13
b
1)
v
N
2)
U, f AT Nr./No./N° Nr./No./N°
[mm] [m/min]   11-122 MA = M MA = R/L
160 0; 6; 9; 12; 15; 18 S; K 3 842 999 083 3 842 999 190
240 0; 6; 9; 12; 15; 18 S; K b = … mm b = … mm
320 0; 6; 9; 12; 15; 18 S; K v
N
= … m/min v
N
= … m/min
400 0; 6; 9; 12; 15; 18 S; K U = … V U = … V
480 0; 6; 9; 12; 15; 18 S; K f = … Hz f = … Hz
640 0; 6; 9; 12; 15; 18 S; K AT = … AT = …
800 0; 6; 9; 12; 15; 18 S; K MA = …
1040 0; 6; 9; 12; 15; 18 S; K
160-1040 0; 6; 9; 12; 15; 18 S; K
b
1)
v
N
2)
U, f AT Nr./No./N° Nr./No./N°
[mm] [m/min]   11-122 MA = M MA = R/L
160 0; 6; 9; 12; 15; 18 S; K 3 842 999 720 3 842 999 721
240 0; 6; 9; 12; 15; 18 S; K b = … mm *) b = … mm
320 0; 6; 9; 12; 15; 18 S; K v
N
= … m/min v
N
= … m/min
400 0; 6; 9; 12; 15; 18 S; K U = … V U = … V
480 0; 6; 9; 12; 15; 18 S; K f = … Hz f = … Hz
640 0; 6; 9; 12; 15; 18 S; K AT = … AT = …
800 0; 6; 9; 12; 15; 18 S; K MA = …
1040 0; 6; 9; 12; 15; 18 S; K
*) b ≥ 240 mm
160-1040 0; 6; 9; 12; 15; 18 S; K
00012916.eps
b
AS 2/B-250
MA=M
AS 2/B-250
MA=R
M
MA = L
R
00116761.eps
150 kg
250 kg
Längstransport · Longitudinal conveyor · Transport longitudinal
3 842 531
138 (2013-06)
Antriebsstation AS 2/B-150
AS 2/B-150 drive module
Poste d’entraînement AS 2/B-150
Antriebsstation AS 2/B-250
AS 2/B-250 drive module
Poste d’entraînement AS 2/B-250
1)
b = Track width in direction of transport
2)
v
N
= Nominal transportation speed;
v
N
= 0: without motor or gear
Special models on request
1)
b = Spurbreite in Transportrichtung
2)
v
N
= Nenngeschwindigkeit;
v
N
= 0: ohne Motor und ohne Getriebe
Sonderausführungen auf Anfrage
1)
b = Ecartement de voie en direction du transport
2)
v
N
= Vitesse nominale de transport ;
v
N
= 0 : sans moteur et sans engrenage
Versions spéciales sur demande
MA = Motoranordnung
MA = Motor layout
MA = Disposition du moteur
