Bosch Rexroth AGTS 2plus 4.2 3–29
b
l
00013196.eps
b
1)
l
2)
v
N
3)
U, f AT MA KA Nr./No./N°
[mm] [mm] [m/min]  11-122
160 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A 3 842 999 917
240 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A b = … mm
320 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A l = … mm
400 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A v
N
= … m/min
480 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A U = … V
640 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A f = … Hz
800 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A AT = …
1040 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; M N; A MA = …
160-1040 300-6000 0; 6; 9; 12; 15; 18 S; K R; L; (M) N; A KA = …
b
1)
l
2)
v
N
3)
U, f AT MA KA Nr./No./N°
[mm] [mm] [m/min]  11-122
160 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A
3 842 999 985
240 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A b = … mm
320 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A l = … mm
400 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A v
N
= … m/min
480 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A U = … V
640 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A f = … Hz
800 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A AT = …
1040 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A MA = …
160-1040 300-6000 0; 6; 9; 12; 15; 18 S; K R; L N; A KA = …
BS 2/C-100
M
MA = L
R
00116761.eps
100 kg
250 kg
Längstransport · Longitudinal conveyor · Transport longitudinal
3 842 531
138 (2013-06)
Bandstrecke BS 2/C-100
BS 2/C-100 belt section
Section à bande BS 2/C-100
Bandstrecke BS 2/C-250
BS 2/C-250 belt section
Section à bande BS 2/C-250
MA = Motoranordnung
MA = Motor layout
MA = Disposition du moteur
1)
b = Spurbreite in Transportrichtung
2)
l = Länge
3)
v
N
= Nenngeschwindigkeit;
v
N
= 0: ohne Motor und ohne Getriebe
Sonderausführungen auf Anfrage
1)
b = Track width in direction of transport
2)
l = Length
3)
v
N
= Nominal transportation speed;
v
N
= 0: without motor or gear
Special models on request
1)
b = Ecart. de voie en direction du transport
2)
l = Longueur
3)
v
N
= Vitesse nominale de transport ;
v
N
= 0 : sans moteur et sans engrenage
Versions spéciales sur demande
