125 • PID Sensor Maintenance GX-6000 Operator’s Manual
7 . Place the PID sensor face down on a flat clean working surface.
NOTE: Do not touch the lamp window with your fingers as this may
contaminate the window with finger oil. At this point it is
recommended that the finger cots be used on the fingers handling
the lamp. Finger cots are included with the lamp cleaning kit.
8 . Hold the PID sensor steady on the working surface with one hand and
using the other hand, locate the tabs on the electrode stack removal tool
and insert them into the slots on the side of the PID sensor near the face.
Figure 28: Using Removal Tool
9 . Squeeze the removal tool to push the tabs into the sensor slots until the
electrode stack and lamp are released.
10 . Carefully lift the PID sensor body away from the electrode stack and
lamp. Take care not to touch the lamp window, the flat end of the lamp,
with your fingers. If the lamp remains lodged in the sensor body,
carefully remove it with tweezers.
Figure 29: Lamp Window Location
