129 • PID Sensor Maintenance GX-6000 Operator’s Manual
Replacing the PID Sensor’s Lamp
If cleaning the PID lamp does not resolve any calibration problems you may
be having, the lamp may need to be replaced.
Ordering the Correct Replacement Lamp
It’s important to order the correct replacement lamp for your PID sensor.
1 . Look at the label(s) on the side of your PID sensor. Some sensors only
have a label that says “PIS-001” or “PIS-002”. Other sensors have a
label that says “PIS-001” or “PIS-002” and another RKI part number
label that says “PID-001L” or “PID-002L”.
2 . See the table below for replacement lamp part numbers based on your
sensor’s label(s).
Steps to Replace the Lamp
Perform the following procedure to replace the PID lamp:
NOTE: Do not touch the new lamp window (the flat end) with your fingers
as this may contaminate the window with finger oil.
1 . Verify that the GX-6000 is off.
2 . Use a small Phillips screwdriver to unscrew the four screws holding the
flow chamber to the rest of the GX-6000’s case.
3 . Grasp the sides of the flow chamber and lift it away from the rest of the
case. The screws are captive screws and will not come out of the flow
chamber.
4 . Gently pull up the edges of the sensor gasket to loosen it from its
connections. Be sure not to lose any of the filters that are in it. The
sensors will be exposed.
5 . Locate the PID sensor.
6 . Grasp the sensor firmly and pull it out of its socket.
Table 15: PID Sensor Replacement Lamp Part Number
Part Number Label(s)
on Sensor
Replacement Lamp
Part Number
PIS-001 51-1500RK
PIS-001 and
PID-001L 51-1503
PIS-002 51-1502
PIS-002 and
PID-002L 51-1503
