RKI Instruments GX-6000 - Viewing Benzene Select Mode Data

GX-6000 Operator’s Manual Viewing Benzene Select Mode Data • 236
f. To return to Measuring Mode, press and release the DISP/LOCK
button. You will be prompted to remove the tube holder from the
instrument’s inlet fitting.
g. Remove the tube holder from the GX-6000’s inlet fitting.
h. Press and release the POWER/ENTER button.
Viewing Benzene Select Mode Data
Readings taken in Benzene Select Mode are saved to the snap logger. To
view Benzene Select Mode readings, do the following:
1 . From Measuring Mode, press and release the DISP/LOCK button to
enter Display Mode.
2 . Continue pressing the DISP/LOCK button until the snap logging screen
appears.
TUBE
REMOVE HOLDER
YES :ENTER
NO :DISP
DISP
REC. DATA DISP
YES :ENTER
NO :DISP
EXIT :RESET
