175 • Overview GX-6000 Operator’s Manual
Appendix B: Maintenance Mode 2
Overview
This appendix describes the GX-6000 in Maintenance Mode 2. The GX-6000
is factory-set to suit most applications. Update settings in Maintenance Mode
2 only if required for your specific application. A description of the
Maintenance Mode 2 items is shown in Table 18 below.
Tips for Using Maintenance Mode 2
• When in the main menu, the cursor (>) indicates which menu item will be
selected if the POWER/ENTER button is pressed and released.
• Use the SHIFT ▼ (PANIC) button to move the cursor down through the
main menu and submenu items, and to lower values or change the setting
in a specific option.
• Use the ▲AIR button to move the cursor up through the main menu and
submenu items, and to raise values or change the setting in a specific
option.
• Use the POWER/ENTER button to enter a menu item with the cursor next
to it and to enter and save settings during programming.
• An adjustable parameter that is flashing can be adjusted with the ▲AIR
and SHIFT ▼ (PANIC) buttons.
• Press the DISP/LOCK button while in a screen where you are entering or
updating parameters to exit the screen without saving any changes. You
can also use the DISP/LOCK button to back out of submenus and return
to the main menu.
Table 18: Maintenance Mode 2 Menu Items
Menu Item (Page # of Description) Description
GAS COMB (pg.178) Turn channels on or off
HC SELECT (pg.179) Set the catalytic LEL channel’s detection gas
START MEASURE (pg.179) Enter Measuring Mode
