GX-6000 Operator’s Manual Display Mode • 60
4 . To view the data in a snap log ID, press and release the POWER/ENTER
button.
The gas readings that were taken during the snap log are displayed. You
can use the ▲AIR and SHIFT ▼ (PANIC) buttons to scroll through the
different snap logs. The gas readings will change as you view different
snap log data but the snap log ID is not visible from this screen. To
scroll through the data by viewing the snap log ID number, press
and release POWER/ENTER.
5 . To return to the Snap Logging Screen, press and release the DISP/LOCK
button.
Peak Bar Screen
The Peak Bar Screen allows you to turn the peak bar on or off. If the function
is turned on, the peak bar appears along the right side of each gas reading in
Measuring Mode and on the Peak Screen in Display Mode. It shows the peak
readings for each channel in bar graph format.
1 . With the Peak Bar Screen displayed, press and release the POWER/
ENTER button. The current setting will be displayed.
2 . Use the ▲AIR and SHIFT ▼ (PANIC) buttons to display the desired
setting.
REC DATA
CH4 O2
%LEL %
H2S CO
ppm ppm
VOC
ppm
0 20.9
0.0 0
0
DISP
PEAK BAR
YES :ENTER
NO :DISP
EXIT :RESET
To Next Page
