GX-6000 Operator’s Manual Display Mode • 62
1 . With the Gas Display Screen showing, press and release the POWER/
ENTER button. The available choices will appear.
2 . Use the â–˛AIR and SHIFT â–Ľ (PANIC) buttons to move the cursor next to
the desired setting.
3 . Press and release the POWER/ENTER button to return to the Gas
Display Screen.
To return to the Gas Display Screen without saving any changes, press
and release the DISP/LOCK button.
LCD Flip Screen
If INVERT SELECT is set to ON, the instrument’s LCD will automatically
flip if the instrument is turned upside down. This allows for the LCD to be
read with the instrument right side up or upside down. If desired, holding
down the DISP/LOCK button will lock the screen in its current position and
keep it from rotating. A LOCK symbol will flash at the top of the screen to
indicate that the LCD’s position is fixed. To unlock the LCD, hold the DISP/
LOCK button until the LOCK symbol disappears.
NOTE: Even if INVERT SELECT is set to ON, the screens in Calibration
Mode, User Mode, and Maintenance Mode will not flip if the
instrument is turned upside down.
DISP
GAS DISP
DISPLAY ALL
SCROLL AUTO
SCROLL MANUAL
To Next Page
