Appendix C: ESS-03 Toxic Sensors
Overview
The ESS-03 sensors are used to monitor levels of a variety of toxic gases.
This appendix describes the GX-6000’s ESS-03 sensors. It also includes
instructions to replace an ESS-03 sensor. Table 19 below lists the available
ESS-03 sensors.
Table 19: ESS-03 Sensor Specifications
NOTE: If you are attempting to detect chlorine, be sure the hose/probe does
not have a particle filter installed. Also be sure that the hose is not
longer than 30 feet.
Description
The ESS-03 is a smart sensor that stores sensor parameters including the
target gas, detection range, alarm points, and calibration settings in its
memory. So a sensor can be calibrated at the factory and shipped as a
replacement sensor without the need to calibrate the sensor when it is
installed as long as it is installed during the sensor’s valid calibration period
which is typically 3 months. In addition, you can change an existing ESS-03
Target Gas Detection
Range
Reading
Increment
Alarm 1
Factory
Setting
Alarm 2
Factory
Setting
STEL TWA
Ammonia
(NH
3
)
0 - 400 ppm 0.5 ppm 25 ppm 50 ppm 35 ppm 25 ppm
Chlorine
(Cl
2
)
0 - 10.0 ppm 0.05 ppm 0.50 ppm 1.00 ppm 1.00 ppm 0.50 ppm
Hydrogen
Cyanide
(HCN)
0 - 15.0 ppm 0.1 ppm 5.00 ppm 10.0 ppm 4.7 ppm N/A
Nitrogen
Dioxide
(NO
2
)
0 - 20.00 ppm 0.05 ppm 3.00 ppm 6.00 ppm N/A 3.00 ppm
Sulphur
Dioxide
(SO
2
)
0 - 99.90 ppm 0.05 ppm 2.00 ppm 5.00 ppm 5.00 ppm 2.00 ppm
