43 • Display Mode GX-6000 Operator’s Manual
Responding to a Panic Alarm
If the user is in a dangerous situation or feels that others must be alerted to
any sort of problem, holding the SHIFT â–¼ (PANIC) button will initiate a
panic alarm.
1 . Press and release the RESET button to silence and reset the alarm.
Display Mode
Two other operating modes are accessible when the GX-6000 is in Measuring
Mode. They are Display Mode and Calibration Mode. This section describes
using the GX-6000 in Display Mode. See Table 9 below for a list of Display
Mode’s menu items, a short description of each item, and the page number
for further description.
Table 9: Display Mode Items
Menu Item (page number) Description
SELECT PID LIST (pg.45) Define the PID channel’s gas name
PEAK (pg.47) View and clear peak readings
STEL (pg.48) View STEL readings (H
2
S, CO, and high range PID only)
TWA (pg.48) View TWA readings (H
2
S, CO, and high range PID only)
ALARM POINTS (pg.49) View the alarm points
OPERATION TIME (pg.51) View the time in operation
DATE AND BATTERY (pg.51) View the date/time, battery voltage, and battery type
LOG REMAIN (pg.52) View the log time remaining
LOG CLEAR (pg.52) Clear the log data
PUMP OFF (pg.54) Turn the pump on or off (if the PUMP OFF DISP item in
Maintenance Mode is set to ON)
USER ID (pg.55) Select the user ID (if the ID DISPLAY item in Maintenance
Mode is set to ON)
STATION ID (pg.57) Select the station ID (if the ID DISPLAY item in
Maintenance Mode is set to ON)
REC. DATA DISP (pg.59) View snap logger data
PEAK BAR (pg.60) Turn the peak bar function on or off
GAS DISP (pg.61) Change how the gas readings are displayed
INVERT SELECT (pg.62) Turn the LCD flip function on or off
CAT (LEL) SENSOR (pg.63) Turn the combustible sensor protection on or off
