17 • Other Accessories GX-6000 Operator’s Manual
2 . Install the charger(s) on the DIN rail. Seat the top of the DIN rail in the
top slot on the back of the charger. Press the bottom of the charger
toward the DIN rail until it locks into place.
Figure 6: Installing a Charger on the DIN Rail
3 . Slide the charger(s) along the DIN rail into the desired position.
4 . Install the end clamps on the left and right side of the charger or bank of
chargers to prevent sliding.
Figure 7: Clamp Installation
DIN Rail
Charger
Clamp
DIN Rail
