WEC8500/WEC8050 (APC) Operation Manual v10.1 323
©Samsung Electronics America
Callee 3C:8B:FE:2E:6F:6A
10.10.10.193 10617 POOR 1.97/1.66/2.68 240,800
----------------------------------------------------------------------------------------
----------------------------------------------------
4 Check the voice signal related log.
WEC8500/configure# show voice sipmsg-log
Time MAC Address Msg Type Dir
SRC IP DST IP AP BSS WLAN Contents
--------------------- ---------------- ------------- -----
----------- ----------- ---- ---------------- ----- -------------
--------
2013-05-12 21:26:45 c8:19:f7:70:89:04 INVITE SEND 10.10.10.65
90.90.1.100 3 f4:d9:fb:24:c8:c2 1 F:9922, T:995
0, RTP:10.10.10.65:21120
2013-05-12 21:26:44 c8:19:f7:70:89:04 200(REGISTER) RECV 90.90.1.100 10.10.10.65
3 f4:d9:fb:24:c8:c2 1 F:9961, T:996
1, Expire:600
2013-05-12 21:26:44 c8:19:f7:70:89:04 REGISTER SEND 10.10.10.65
90.90.1.100 3 f4:d9:fb:24:c8:c2 1 F:9961, T:996
1, Expire:600
2013-05-12 21:26:44 c8:19:f7:70:89:04 401(REGISTER) RECV 90.90.1.100
10.10.10.65 3 f4:d9:fb:24:c8:c2 1 F:9961, T:996
1, Expire:0
2013-05-12 21:26:44 c8:19:f7:70:89:04 REGISTER SEND 10.10.10.65
90.90.1.100 3 f4:d9:fb:24:c8:c2 1 F:9961, T:996
1, Expire:
5 Check a WLAN event related to a voice.
WEC8500# show voice event
Event Type MAC Address AP BSS WLAN
Time Contents
------------------- ---------------- ---- ----------------- ---
-------------------- ----------------------------
Deassoc During Call 78:47:1D:C2:18:11 3 F4:D9:FB:24:C8:D1 1
2013-05-12 21:22:04 wlan disconncted in AP(3) BSSID(f4:d9:fb:24:c8:d1) during call
caller(9907)  callee(9950) duration(5)sec
CallStop C8:19:F7:70:89:04 3 F4:D9:FB:24:C8:C2 1
2013-05-12 21:22:04 caller(9922)  callee(9950) duration(62)sec
CallConnect 78:47:1D:C2:18:11 3 F4:D9:FB:24:C8:D1 1
2013-05-12 21:22:01 caller(9907)  callee(9950)
CallSetup 78:47:1D:C2:18:11 3 F4:D9:FB:24:C8:D1 1
2013-05-12 21:21:59 caller(9907)  callee(9950)
CallStop 78:47:1D:C2:18:11 3 F4:D9:FB:24:C8:D1 1
2013-05-12 21:21:47 caller(9907)  callee(9950) duration(6)sec
CallConnect 78:47:1D:C2:18:11 3 F4:D9:FB:24:C8:D1 1
2013-05-12 21:21:47 caller(9907)  callee(9950)
6 Check the voice related statistics.
WEC8500# show voice statistics radio
RADIO (5G) Voice Statistis
------ ------ ------- ------ ----- --- ------ ------ --- ------ ------
Type Total Success Failed Active UpstreamTime Downstream
Calls Call Call Call MOS Jitter Delay MOS Jitter Delay
------ ------ ------- ------ ----- --- ------ ------ --- ------ ------
Total 8 6 0 2 0.0 0 0 0.0 0 0
5 Min 0 0 0 0 0.0 0 0 0.0 0 0
15 Min 0 0 0 0 0.0 0 0 0.0 0 0
1 Hour 0 0 0 0 0.0 0 0 0.0 0 0
1 Day 8 6 0 2 0.0 0 0 0.0 0 0
RADIO (2.4G) Voice Statistis
