This command configures the mode of switch port to trunk. The ‘no’ parameter is used to
delete the configuration.
• switchport trunk allowed vlan: Configure VLAN to the trunk mode.
• switchport trunk allowed vlan all: Configure all the VLANs to the trunk
mode.
• switchport trunk allowed vlan none: Stops VLAN data
transmission/reception.
• switchport trunk allowed vlan add [VLAN_ID]: Adds VLAN to the trunk
mode.
• switchport trunk allowed vlan remove [VLAN_ID]: Removes VLAN with
the trunk mode.
• no switchport trunk vlan: Removes all the trunk settings.
[show vlan]
This command retrieves VLAN configuration status.
• show vlan [VLAN_ID]: Displays specific VLAN information.
• show vlan all bridge 1: Displays all the VLAN information.
• show vlan brief: Displays all the VLAN information briefly.
• show vlan dynamic bridge 1: Displays dynamic VLAN information.
• show vlan static bridge 1: Displays static VLAN information.
[Typical configuration procedure]
The typical configuration procedure of VLAN is as follows:
WEC8500# configure terminal
WEC8500/configure# bridge 1 protocol mstp
WEC8500/configure # vlan database
WEC8500/configure/vlan#vlan {2-4094} bridge 1
WEC8500/configure/vlan# exit
WEC8500/configure# interface vlan1.{2-4094}
Configuration using Web UI
In the menu bar of <WEC Main window>, select <Configuration> and then select the
<Controller>  <Interfaces> menu in the sub-menus.
For more information about configuration procedure, see ‘Interface Management’ part in
‘Data Network Function’ chapter.
Bridge
To set up bridge related functions, go to configure mode by executing the following
command:
WEC8500# configure terminal
The bridge related commands are as follows:
