Semco RC100C-2 - Chapter 10 Data Formats Supported by RC100 C-2

A2537-002/01 February 2020 8-2 SEMCO Proprietary Information
Table 8-1
Chapter 10 Data Formats Supported by RC100C-2
Packet
Header Value
Data Type Name
Data Type Description
Current Data
Type Version
0x00
Computer-Generated Data, Format 0
User - Defined
0x06
0x01
Computer-Generated Data, Format 1
Setup Record
0x08
0x02
Computer-Generated Data, Format 2
Recording Events
0x06
0x03
Computer-Generated Data, Format 3
Recording Index
0x06
0x04
Computer-Generated Data, Format 4
Streaming Configuration Records
0x08
0x05 - 0x07
Computer-Generated Data, Format 5 -7
Reserved for Future Use
0x06
0x08
PCM Data, Format 0
Reserved for Future Use
0x06
0x09
PCM Data, Format 1
Chapter 4 or 8
0x06
0x0A - 0x0F
PCM Data, Format 2 – 7
Reserved for Future Use
0x06
0x10
Time Data, Format 0
Reserved for Future Use
0x06
0x11
Time Data, Format 1
RCC/GPS/Relative Time Counter
0x06
0x12
Time Data, Format 2
Network Time
0x08
0x03 - 0x17
Time Data, Format 3 - 7
Reserved for Future Use
0x06
0x18
MIL-STD-1553 Data, Format 0
Reserved for Future Use
0x06
0x19
MIL-STD-1553 Data, Format 1
MIL-STD-1553B Data
0x06
0x1A
MIL-STD-1553 Data, Format 2
16PP194 Bus
0x06
0x1B – 0x1F
MIL-STD-1553 Data, Format 3 - 7
Reserved for Future Use
0x06
0x20
Analog Data, Format 0
Reserved for Future Use
0x06
0x21
Analog Data, Format 1
Analog Data
0x06
0x22 - 27
Analog Data, Format 2 - 7
Reserved for Future Use
0x06
0x28
Discrete Data, Format 0
Reserved for Future Use
0x06
0x29
Discrete Data, Format 1
Discrete Data
0x06
0x2A - 2F
Discrete Data, Format 2 - 7
Reserved for Future Use
0x06
0x30
Message Data, Format 0
Generic Message Data
0x06
0x31 - 37
Message Data, Format 1 - 7
Reserved for Future Use
0x06
0x38
ARINC-429 Data, Format 0
ARINC-429 Data
0x06
0x39 - 3F
ARINC-429 Data, Format 1 - 7
Reserved for Future Use
0x06
0x40
Video Data, Format 0
MPEG-2/H.264 Video
0x06
0x41
Video Data, Format 1
ISO 13818-1 MPEG-2
0x06
0x42
Video Data, Format 2
ISO 14496-10 MPEG-4
Part 10 AVC/ITU H.264
0x06
0x43
Video Data, Format 3
MJPEG
0x07
0x44
Video Data, Format 4
MJPEG 2000
0x07
0x45 - 47
Video Data, Format 5 - 7
Reserved for Future Use
0x06
0x48
Image Data, Format 0
Image Data
0x06
0x49
Image Data, Format 1
Still Imagery
0x06
0x4A
Image Data, Format 2
Dynamic Imagery
0x06
0x4B - 4F
Image Data, Format 3 - 7
Reserved for Future Use
0x06
0x50
UART Data, Format 0
UART Data
0x06
0x51 - 57
UART Data, Format 1 - 7
Reserved for Future Use
0x06
0x58
IEEE 1394, Format 0
IEEE 1394 Transaction
0x06
0x59
IEEE 1394, Format 1
IEEE 1394 Physical Layer
0x06
0x5A - 5F
IEEE 1394, Format 2 - 7
Reserved for Future Use
0x06
0x60
Parallel Data, Format 0
Parallel Data
0x06
0x61 - 67
Parallel Data, Format 1 - 7
Reserved for Future Use
0x06
0x68
Ethernet Data, Format 0
Ethernet Data
0x07
0x69
Ethernet Data, Format 1
Ethernet UDP Payload
0x06
0x6A - 6F
Ethernet Data, Format 2 - 7
Reserved for Future Use
0x06
0x70
TSPI/CTS Data, Format 0
GPS NMEA-RTCM
0x06
0x71
TSPI/CTS Data, Format 1
EAG ACMI
0x06
0x72
TSPI/CTS Data, Format 2
ACTTS
0x06
0x73 - 77
TSPI/CTS Data, Format 3 - 7
Reserved for Future Use
0x06
0x78
Controller Area Network Bus
CAN Bus
0x06
0x79
Fiber Channel Data, Format 0
Fiber Channel Data
0x07
0x7A
Fiber Channel Data, Format 1
Fiber Channel Data
0x08
0x7B - 80
Fiber Channel Data, Format 2 - 7
Reserved for Future Use
0x08
