Siemens SINUMERIK 808D Function Manual

Function Manual
114 01/2017
Interpolation points
Table <t>
[0,<N>]
Number of interpola-
tion points
MD18342 $MN_MM_CEC_MAX_POINTS[0] =
11
Interpolation point
<N>
0
1
2
3
4
5
6
7
8
9
10
Position X
-585
-527
-469
-411
-353
-295
-237
-179
-121
-63
-5
Measurement
Setpoint posi-
tion
Deviation
Checking measurement
Position
Comp. No.
Measurement
position
[mm]
Direction +
[mm]
Direction -
[mm]
Direction +
[mm]
Direction -
[mm]
$AN_CEC_MIN[<t>]
-585
0
-585
0.0000
0.0020
0.0000
-0.0008
1
-527
0.0010
0.0017
-0.0005
-0.0001
2
-469
0.0040
0.0053
-0.0001
-0.0009
3
-411
0.0034
0.0061
0.0001
-0.0009
4
-353
0.0013
0.0030
-0.0005
-0.0006
5
-295
0.0004
0.0016
-0.0002
-0.0003
6
-237
0.0016
0.0027
-0.0004
-0.0007
7
-179
0.0026
0.0043
-0.0004
-0.0004
8
-121
-0.0010
0.0026
0.0000
-0.0011
9 -63 -0.0023 0.0000 -0.0011 -0.0003
$AN_CEC_MAX[<t>]
-5
10
-5
-0.0031
-0.0012
-0.0001
-0.0012
