Siemens SINUMERIK 808D Function Manual

Function Manual
01/2017
115
Programming
The following program "BI_SSFK_TAB_AX1_X.MPF" includes the value assignments for the parameters of the two
compensation tables (positive and negative traversing direction) of the X axis:
;direction-dependent LEC
;1st axis MX1
;Table 1 - positive traversing direction
;Table 2 - negative traversing direction
;--------------------------------------------------------------------------------------
CHANDATA(1)
$MA_CEC_ENABLE[AX1]=0
;compensation OFF
$SN_CEC_TABLE_ENABLE[0]=0
;lock Table 1
$SN_CEC_TABLE_ENABLE[1]=0
;lock Table 2
NEWCONF
;--------------------------------------------------------------------------------------
$AN_CEC[0,0]=0
;1st compensation value (interpolation point 0)
$AN_CEC[0,1]=0.001
;2nd compensation value (interpolation point 1)
$AN_CEC[0,2]=0.004
;3rd compensation value (interpolation point 2)
$AN_CEC[0,3]=0.0034
;4th compensation value (interpolation point 3)
$AN_CEC[0,4]=0.0013
;5th compensation value (interpolation point 4)
$AN_CEC[0,5]=0.0004
;6th compensation value (interpolation point 5)
$AN_CEC[0,6]=0.0016
;7th compensation value (interpolation point 6)
$AN_CEC[0,7]=0.0026
;8th compensation value (interpolation point 7)
$AN_CEC[0,8]=-0.001
;9th compensation value (interpolation point 8)
$AN_CEC[0,9]=-0.0023
;10th compensation value (interpolation point 9)
$AN_CEC[0,10]=-0.0031
;last compensation value (interpolation point 10)
$AN_CEC_INPUT_AXIS[0]=(AX1)
;basic axis
$AN_CEC_OUTPUT_AXIS[0]=(AX1)
;compensation axis
$AN_CEC_STEP[0]=58.0
;interpolation point distance
$AN_CEC_MIN[0]=-585.0
;compensation starts
$AN_CEC_MAX[0]=-5.0
;compensation ends
$AN_CEC_DIRECTION[0]=1
;Table applies for positive traversing directions
$AN_CEC_MULT_BY_TABLE[0]=0
;no multiplication (not relevant here)
$AN_CEC_IS_MODULO[0]=0
;compensation without modulo function
;--------------------------------------------------------------------------------------
$AN_CEC[1,0]=0.002
;(interpolation point 0)
$AN_CEC[1,1]=0.0017
;(interpolation point 1)
$AN_CEC[1,2]=0.0053
;(interpolation point 2)
$AN_CEC[1,3]=0.0061
;(interpolation point 3)
$AN_CEC[1,4]=0.003
;(interpolation point 4)
$AN_CEC[1,5]=0.0016
;(interpolation point 5)
$AN_CEC[1,6]=0.0027
;(interpolation point 6)
$AN_CEC[1,7]=0.0043
;(interpolation point 7)
$AN_CEC[1,8]=0.0026
;(interpolation point 8)
$AN_CEC[1,9]=0.000
;(interpolation point 9)
$AN_CEC[1,10]=-0.0012
;(interpolation point 10)
$AN_CEC_INPUT_AXIS[1]=(AX1)
;basic axis
$AN_CEC_OUTPUT_AXIS[1]=(AX1)
;compensation axis
$AN_CEC_STEP[1]=58.
;interpolation point distance
$AN_CEC_MIN[1]=-585.0
;compensation starts
$AN_CEC_MAX[1]=-5.0
;compensation ends
$AN_CEC_DIRECTION[1]=-1
;Table applies for negative traversing directions
$AN_CEC_MULT_BY_TABLE[1]=0
;no multiplication (not relevant here)
$AN_CEC_IS_MODULO[1]=0
;compensation without modulo function (only for rotary axes)
;--------------------------------------------------------------------------------------
$MA_CEC_ENABLE[AX1]=1
;compensation ON
$SN_CEC_TABLE_ENABLE[0]=1
;enable Table 1
$SN_CEC_TABLE_ENABLE[1]=1
;enable Table 2
NEWCONF
M17
Additional tables can be set-up, e.g. for axes Y and Z:
MD18342 $MN_MM_CEC_MAX_POINTS[
2
] = 90 (Table
3
: Axis
Y
, positive traversing direction)
MD18342 $MN_MM_CEC_MAX_POINTS[
3
] = 90 (Table
4
: Axis
Y
, negative traversing direction)
MD18342 $MN_MM_CEC_MAX_POINTS[
4
] = 50 (Table
5
: Axis
Z
, positive traversing direction)
MD18342 $MN_MM_CEC_MAX_POINTS[
5
] = 50 (Table
6
: Axis
Z
, negative traversing direction)
