MD20080 AXCONF_CHANAX_NAME_TAB[2]="C"
MD20080 AXCONF_CHANAX_NAME_TAB[3]="SP2"
MD20080 AXCONF_CHANAX_NAME_TAB[4]=""
● Initial setting of master spindle in channel
MD20090 SPIND_DEF_MASTER_SPIND=1
TRACYL transformation type for second transformation:
● Without groove wall offset (no YM axis)
MD24100 TRAFO_TYPE_2=512
● Axis assignment in channel
MD24110 TRAFO_AXES_IN_2[0]=1
MD24110 TRAFO_AXES_IN_2[1]=3
MD24110 TRAFO_AXES_IN_2[2]=2
MD24110 TRAFO_AXES_IN_2[3]=0
MD24110 TRAFO_AXES_IN_2[4]=0
● Assignment of geometry axes to channel axes
MD24120 TRAFO_GEOAX_ASSIGN_TAB_2[0]=1
MD24120 TRAFO_GEOAX_ASSIGN_TAB_2[1]=3
MD24120 TRAFO_GEOAX_ASSIGN_TAB_2[2]=2
Special TRACYL settings:
● Offset of rotary axis
MD24800 TRACYL_ROT_AX_OFFSET_1=0
● Sign of rotary axis
MD24810 TRACYL_ROT_SIGN_IS_PLUS_1=1
● Vector of base tool
MD24820 TRACYL_BASE_TOOL_1[0]=0
MD24820 TRACYL_BASE_TOOL_1[1]=0
MD24820 TRACYL_BASE_TOOL_1[2]=0
Setting data for the special treatment of the tool offset (only when required):
● Change of tool length component for change of plane
SD42940 TOOL_LENGTH_CONST=18
● Assignment of the tool length offset independent of tool type
SD42950 TOOL_LENGTH_TYPE=2
Settings for second spindle (milling spindle of the lathe):
● MD30300 IS_ROT_AX[AX4]=1
● MD30310 ROT_IS_MODULO[AX4]=1
● MD30320 DISPLAY_IS_MODULO[AX4]=1
● MD35000 SPIND_ASSIGN_TO_MACHAX[AX4]=2
● SD43300 ASSIGN_FEED_PER_REV_SOURCE[AX4]=0
Note
A special handling of milling tools on lathes with respect to length compensation is possible.
