Siemens SINUMERIK 828D Function Manual

P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1043
Channel signals
Feedrate, spindle signals
Checkback signals from user interface for controlling displays
Operating modes and machine functions
Source:
MCP - Switch
Destination:
Interface DB (all axis DBs)
Feedrate override DB31, ... .DBB0 (selected axis number) The feed
override of the 1st MCP is applied to all axes.
Spindle override DB31, ... .DBB19 (parameter SpindleIFNo)
Source:
MCP - Keys
Destination:
Interface DB (parameter ChanNo)
NC start DB21, ... .DBX7.1
NC stop DB21, ... .DBX7.3
RESET DB21, ... .DBX7.7
Single BLock DB21, ... .DBX0.4
Source:
MCP - Keys
Destination:
FC output parameters
Feed stop
Feed enable
Parameter: "FeedHold" linked with memory, LED
are controlled
Spindle stop
Spindle enable
Parameter: "SpindleHold" linked with memory,
LED are controlled
Destination:
MCP - LED
Source:
Interface DB (parameter BAGNo)
Display for BAG1
AUTOMATIC DB11.DBX6.0
MDA DB11.DBX6.1
JOG DB11.DBX6.2
REPOS DB11.DBX7.1
REF DB11.DBX7.2
TEACH IN DB11.DBX7.0
Aim:
MCP - LED
Source:
Interface DB (parameter BAGNo)
Display for BAG1
INC 1 ... 10 000, INC Var. DB11.DBX2.0 - 8.5
