Siemens SINUMERIK 828D Function Manual

P3: Basic PLC Program for SINUMERIK 840D sl
13.13 Block descriptions
Basic Functions
1042 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Operating modes and machine functions
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The associated interface bits are deleted for axes, which are
not selected.
Override
Source:
MCP - Key
Destination:
Interface DB (parameter BAGNo)
Display for BAG1
AUTOMATIC DB11.DBX0.0
MDI DB11.DBX0.1
JOG DB11.DBX0.2
REPOS DB11.DBX1.1
REF DB11.DBX1.2
TEACH IN DB11.DBX1.0
INC 1 ... 10 000, INC Var. DB11.DBX2.0 - 2.5
Source:
MCP - Key
Destination:
Interface DB (parameter ChanNo)
Direction key + DB21, ... .DBX12.7
Direction key - DB21, ... .DBX12.6
Rapid traverse override DB21, ... .DBX12.5
Direction key + DB21, ... .DBX16.7
Direction key - DB21, ... .DBX16.6
Rapid traverse override DB21, ... .DBX16.5
Direction key + DB21, ... .DBX20.7
Direction key - DB21, ... .DBX20.6
Rapid traverse override DB21, ... .DBX20.5
Source:
MCP - Key
Destination:
Interface DB (all axis DBs)
Direction key + DB31, ... .DBX4.7
Direction key - DB31, ... .DBX4.6
Rapid traverse override DB31, ... .DBX4.5
Source:
MCP - Switch
Destination:
Interface DB (parameter ChanNo)
Feedrate override DB21, ... .DBB4
