Siemens SINUMERIK 828D Function Manual

P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1159
Variable rpa
R-variables
Variable actLineNumber
Line number of the actual NC block (from 1)
Variable magazine data: Location data
Location type ($TC_MPP2)
Variable rpa [r/w]
DB120x.DBB1000 5
DB120x.DBB1001 -
DB120x.DBW1002 R number + 1
DB120x.DBW1004 -
DB120x.DBD1008 Write: Data to NCK variable x (data type of the variables: REAL)
DB120x.DBW3004 Read: Data from NCK variable x (data type of the variables: REAL)
0: Prior to program start
-1: Not available due to error
-2: Not available due to DISPLOF
Variable actLineNumber [r]
DB120x.DBB1000 6
DB120x.DBB1001 -
DB120x.DBW1002 -
DB120x.DBW1004 -
DB120x.DBD1008 -
DB120x.DBW3004 Read: Data from NCK variable x (data type of the variables: INT)
Location type: $TC_MPP2
Address Description Valid values
DB120x.DBB1000 Variables index 7
DB120x.DBB1001 - -
DB120x.DBW1002 Location number 1 … 31999
DB120x.DBW1004 Magazine number 1 … 9999
