P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
1160 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Location status ($TC_MPP4)
T No. of tool at this location ($TC_MPP6)
DB120x.DBD1008 - -
DB120x.DBW3004 Result: Value of the NCK variable x > 0 Location type for virtual location
Data type: WORD 0 "match all" (buffer)
9999 undefined (no virtual location)
Location state: $TC_MPP4
Address Description Valid values
DB120x.DBB1000 Variables index 8
DB120x.DBB1001 - -
DB120x.DBW1002 Location number 1 … 31999
DB120x.DBW1004 Magazine number 1 … 9999
DB120x.DBD1008 - -
DB120x.DBW3004 Result: Value of the NCK variable x 1 Blocked
2 free (<> occupied)
4 reserved for tool in buffer
8 reserved for tool to be loaded
16 occupied in left half location
32 occupied in right half location
64 occupied in upper half location
128 occupied in lower half location
T number of the tool at this location: $TC_MPP6
Address Description Valid values
DB120x.DBB1000 Variables index 9
DB120x.DBB1001 - -
DB120x.DBW1002 Location number 1 … 31999
DB120x.DBW1004 Magazine number 1 … 9999
DB120x.DBD1008 - -
DB120x.DBW3004 Result: T number of the tool at this
location
T number of the tool
Location type: $TC_MPP2
Address Description Valid values
