P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
1162 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Variable r0082[1]
CO: Active power actual value [kW]
Index: [1] = Smoothed with p0045
Variables: Temperature compensation
Variable TEMP_COMP_ABS_VALUE (SD43900)
Position-independent temperature compensation value
Variable TEMP_COMP_SLOPE (SD43910)
Gradient for position-dependent temperature compensation
Variable r0082[0…2] [r]
DB120x.DBB1000 13
DB120x.DBB1001 Number of the drive module
DB120x.DBW1002 -
DB120x.DBW1004 -
DB120x.DBD1008 -
DB120x.DBW3004 Read: Data from NCK variable x (data type of the variables: REAL)
Variable TEMP_COMP_ABS_VALUE [r/w]
DB120x.DBB1000 14
DB120x.DBB1001 No. of the axis (1, 2, ...)
DB120x.DBW1002 -
DB120x.DBW1004 -
DB120x.DBD1008 Write: Data to NCK variable x (data type of the variables: REAL)
DB120x.DBW3004 Read: Data from NCK variable x (data type of the variables: REAL)
Variable TEMP_COMP_SLOPE [r/w]
DB120x.DBB1000 15
DB120x.DBB1001 No. of the axis (1, 2, ...)
DB120x.DBW1002 -
DB120x.DBW1004 -
DB120x.DBD1008 Write: Data to NCK variable x (data type of the variables: REAL)
DB120x.DBW3004 Read: Data from NCK variable x (data type of the variables: REAL)
