A3: Axis Monitoring, Protection Zones
2.5 Examples
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
135
Table 2-3 Protection zone: Workpiece and tool holder
System variable Valu
e
Comment
$SN_PA_ACTIV_IMMED[0] 0 ; Protection zone for workpiece not immediately active
$SN_PA_ACTIV_IMMED[1] 0 ; Protection zone for tool holder not immediately active
$SC_PA_TW[0] " " ; Protection zone for workpiece, channel-specific
$SC_PA_TW[1] 'H01' ; Protection zone for toolholder, channel-specific
$SC_PA_ORI[0] 1 ; Orientation of the protection zone: 1= 3. and first geometry
axis
; Protection zone for workpiece
$SC_PA_ORI[1] 1 ; Orientation of the protection zone: 1= 3. and first geometry
axis
; Protection zone for tool holder
$SC_PA_LIM_3DIM[0] 0 ; Type of limitation in the third dimension: 0 = no limitation
; Protection zone for workpiece tool holder 0
$SC_PA_LIM_3DIM[1] 0 ; Type of limitation in the third dimension: 0 = no limitation
; Protection zone for tool holder
$SC_PA_PLUS_LIM[0] 0 ; Value of limitation in positive direction in the third dimension
; Protection zone for workpiece
$SC_PA_PLUS_LIM[1] 0 ; Value of limitation in positive direction in the third dimension
; Protection zone for tool holder
$SC_PA_MINUS_LIM[0] 0 ; Value of limitation in negative direction in the third dimension
; Protection zone for workpiece
$SC_PA_MINUS_LIM[1] 0 ; Value of limitation in negative direction in the third dimension
; Protection zone for tool holder
$SC_PA_CONT_NUM[0] 4 ; Number of valid contour elements,
; Protection zone for workpiece
$SC_PA_CONT_NUM[1] 5 ; Number of valid contour elements,
; Protection zone for tool holder 1
$SN_PA_CONT_TYP[0,0] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 0
$SN_PA_CONT_TYP[0,1] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 1
$SN_PA_CONT_TYP[0,2] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 2
$SN_PA_CONT_TYP[0,3] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 3
$SN_PA_CONT_TYP[0,4] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for workpiece, contour element 4
$SN_PA_CONT_TYP[0,5] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 5
$SN_PA_CONT_TYP[0,6] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 6
$SN_PA_CONT_TYP[0,7] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 7
$SN_PA_CONT_TYP[0,8] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 8
