A3: Axis Monitoring, Protection Zones
2.5 Examples
Basic Functions
136 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
$SN_PA_CONT_TYP[0,9] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_TYP[1,0] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_TYP[1,1] 3 ; Contour type[i] : 3 = G3 f. Circuit element, counter-clockwise,
; Protection zone for tool holder, contour element 1
$SN_PA_CONT_TYP[1,2] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 2
$SN_PA_CONT_TYP[1,3] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 3
$SN_PA_CONT_TYP[1,4] 1 ; Contour type[i] : 1 = G1 for even,
; Protection zone for tool holder, contour element 4
$SN_PA_CONT_TYP[1,5] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 5
$SN_PA_CONT_TYP[1,6] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 6
$SN_PA_CONT_TYP[1,7] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 7
$SN_PA_CONT_TYP[1,8] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 8
$SN_PA_CONT_TYP[1,9] 0 ; Contour type[i] : 0 = not defined,
; Protection zone for tool holder, contour element 9
$SN_PA_CONT_ORD[0,0] -80 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 0
$SN_PA_CONT_ORD[0,1] -80 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 1
$SN_PA_CONT_ORD[0,2] 80 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 2
$SN_PA_CONT_ORD[0,3] 80 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 3
$SN_PA_CONT_ORD[0,4] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 4
$SN_PA_CONT_ORD[0,5] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 5
$SN_PA_CONT_ORD[0,6] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 6
$SN_PA_CONT_ORD[0,7] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 7
$SN_PA_CONT_ORD[0,8] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 8
$SN_PA_CONT_ORD[0,9] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_ORD[1,0] -190 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_ORD[1,1] -210 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 1
Table 2-3 Protection zone: Workpiece and tool holder
