Siemens SINUMERIK 828D Function Manual

A3: Axis Monitoring, Protection Zones
2.5 Examples
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
137
$SN_PA_CONT_ORD[1,2] -210 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 2
$SN_PA_CONT_ORD[1,3] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 3
$SN_PA_CONT_ORD[1,4] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 4
$SN_PA_CONT_ORD[1,5] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 5
$SN_PA_CONT_ORD[1,6] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 6
$SN_PA_CONT_ORD[1,7] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 7
$SN_PA_CONT_ORD[1,8] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 8
$SN_PA_CONT_ORD[1,9] 0 ; Endpoint of contour[i], ordinate value
; Protection zone for tool holder, contour element 9
$SN_PA_CONT_ABS[0,0] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 0
$SN_PA_CONT_ABS[0,1] 40 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 1
$SN_PA_CONT_ABS[0,2] 40 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 2
$SN_PA_CONT_ABS[0,3] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 3
$SN_PA_CONT_ABS[0,4] -50 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 4
$SN_PA_CONT_ABS[0,5] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 5
$SN_PA_CONT_ABS[0,6] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 6
$SN_PA_CONT_ABS[0,7] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 7
$SN_PA_CONT_ABS[0,8] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 8
$SN_PA_CONT_ABS[0,9] 0 ; Endpoint of contour[i], abscissa value
; Protection zone for workpiece, contour element 9
$SN_PA_CONT_ABS[1,0] -50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 0
$SN_PA_CONT_ABS[1,1] -30 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 1
$SN_PA_CONT_ABS[1,2] 20 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 2
$SN_PA_CONT_ABS[1,3] 50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 3
$SN_PA_CONT_ABS[1,4] -50 ; Endpoint of contour[i], abscissa value
; Protection zone for tool holder, contour element 4
Table 2-3 Protection zone: Workpiece and tool holder

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
