W1: Tool offset
18.6 Toolholder with orientation capability
Basic Functions
1510 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
The two rotary axes intersect at one point.
All components of l
2
are therefore zero.
The first rotary axis lies in the x/z plane, the second rotary axis is parallel to the x axis.
These conditions define the directions of v
1
and v
2
(the lengths are irrelevant, provided that they are not equal
to zero).
The reference point of the toolholder lies 200 mm in the negative x direction viewed from the intersection of
the two rotary axes.
This condition defines l
1
.
Specify associated data block values
The following associated data block values are specified for the toolholder shown on a machine with rotary
toolholder:
Description NCK variables Value
x component of offset vector l
1
$TC_CARR1 - 200
y component of offset vector l
1
$TC_CARR2 0
z component of offset vector l
1
$TC_CARR3 0
x component of offset vector l
2
$TC_CARR4 0
y component of offset vector l
2
$TC_CARR5 0
z component of offset vector l
2
$TC_CARR6 0
x component of rotary axis v
1
$TC_CARR7 1
y component of rotary axis v
1
$TC_CARR8 0
z component of rotary axis v
1
$TC_CARR9 0
x component of rotary axis v
2
$TC_CARR10 -1
y component of rotary axis v
2
$TC_CARR11 0
z component of rotary axis v
2
$TC_CARR12 1
Angle of rotation α1 (in degrees) $TC_CARR13 0
Angle of rotation α2 (in degrees) $TC_CARR14 0
x component of offset vector l
3
$TC_CARR15 -100
y component of offset vector l
3
$TC_CARR16 0
z component of offset vector l
3
$TC_CARR17 0
